EZ Loader GT
Equipment Trailer
Adjustable Cast Coupler
6 Hole Adjustable Rail With Auto Latch Cast Zinc Coupler
Gravity Tilt
Low Pro Gravity Tilt. Approximately 11 Degree Load Angle With Fully Enclosed Hydraulic Dampening System With Locking Valve
10 Degree Load Angle
10 Degree Load Angle With Needle Point Dove For Smooth Transitions
Adjustable Cast Coupler
6 Hole Adjustable Rail With Auto Latch Cast Zinc Coupler
Stake Pockets
16' O.C. Stake Pockets HD Rub Rail
EZ Lube Axles
EZ Lube Axles For Quick And Easy Maintenance
LED Lighting
Lifetime LED Flush Mount Lighting
Steel Tread Plate Fenders
HD Steel Treadplate Double Broke Fenders With Tear Drop And Front & Back Gussets
10 Ply Radial Tires
235-80R-16 10 Ply Tires With Silver Mod Wheels
HD Commercial Grade Slipper Spring Suspension
Heavy Duty Commercial Grade Slipper Spring Suspension (on 14k Models)
Double Electric Brakes
Double Electric Brakes Standard On 14k Models
Wrapped Tongue W/ Built In Step To Deck
Built In Step To Deck With Wrapped Tongue
Flooring Double Screwed
Floor Double Screwed Every 4ft
Pressure Treated Decking
Pressure Treated Decking
EZ Steps
EZ Steps On Both Sides For Easy Access
Heavy Duty D-Rings
4 Heavy Duty 5k D-Rings
Tool Box
Flush Mount Tool Box With Grease-able Hinges
Removable Safety Chains
35" Grade 70, Removable Safety Chains With Weather Hangers
12k Spring Loaded Jack
Removable 12k Spring Loaded Jack With Extended Handle
Cushion Tilt Cylinder
Cushion Cylinder For Smooth Tilting Action With Close-able Valve To Lock In The Open Position
Show Features?
Media
Series
7,000lbs GVWR
- 82" x 18'
9,990lbs. GVWR
- 82" x 18'
- 82" x 20'
14,000lbs GVWR
- 82" x 18'
- 82" x 20'
- 82" x 22'
Color Options
About the Trailer
The EZ Loader GT trailers are a game-changer for those who prioritize ease of use and efficiency. With its tilt feature powered by gravity, there's no need to fuss with levers or buttons, simplifying the loading and unloading process significantly. Additionally, the lower load angle is a valuable feature, especially for equipment with low ground clearance, as it ensures smoother and safer loading and unloading operations. With the EZ Loader GT, you get both convenience and practicality, making it an excellent choice for various hauling needs.
Key Features
Expand
Close All
Wrap Tongue with Step to Deck
Ensure durability and accessibility with a wrap tongue featuring a step to the deck, providing sturdy support and convenient entry to the trailer deck, facilitating ease of use and safety during loading and unloading activities.
4 Heavy Duty D-Rings
Secure your cargo with confidence using four heavy-duty D-rings, offering robust anchor points for securing heavy loads during transport, ensuring stability and safety on the road.
EZ Step
Facilitate safe and easy access to your trailer with an EZ step, strategically placed for convenient entry and exit, ensuring enhanced accessibility and safety during loading and unloading operations.
LED Lights
Illuminate your surroundings with energy-efficient LED lights, providing bright and reliable visibility for safer travels, day or night, while reducing power consumption for added efficiency and durability.
Stake Pockets with 3/8″ Rub Rail
Customize your trailer setup with stake pockets featuring a 3/8-inch rub rail, offering versatile attachment points for securing cargo and providing added protection against shifting loads.
Locking Valve on Cylinder
Ensure controlled and secure operation with a locking valve on the cylinder, providing enhanced safety and stability during lifting and lowering operations, ensuring reliable performance and peace of mind.
Radial Tires
Experience superior performance and longevity with radial tires, featuring reinforced sidewalls and advanced tread patterns for enhanced traction, stability, and durability, ensuring reliable performance under various road conditions.
12K Drop leg Spring Assisted Jack
Facilitate effortless hitching and unhitching operations with a 12K drop-leg spring-assisted jack, offering reliable support and stability for your trailer while reducing physical strain and ensuring efficient setup and teardown processes.
Standard Features
- Variable Rate Valve to Control Tilt Function
- Very Low Load Angle
- Wrapped Tongue w/ Step to Deck
- Stake Pocket Tie-Downs & Chain Sliders Along Both Sides
- Stake Pockets with 3/8″ Rub Rail
- 2″ Treated Pine
- Pre-Wired 7-Way RV Plug
- Slipper Spring Suspension
- Break-Away Switch w/ Battery
- LED Lights
- Colors: Black, Red and Grey
- 35″ Grade 70, Removable Safety Chains Removable w HD Hooks
- 6″ High Bump Rail
- Deburred and Hand Prepped Before Painting
- Bolted on 7K Dropleg Jack (12k Dropleg Jack on 14k)
- EZ Steps
- 4 Heavy Duty D-Rings
- 3″ Channel Crossmembers on 16″ Centers
- Finish is a 2 Component Epoxy Primer & 2 Component Polyurethane Paint
- Removable Safety Chains w Weather Hangers
Trailer Options
Expand
Close All
Miscellaneous
- No Dove CF/Xtreme
- No Dove No Ramps
- Coupler, Adjustable (Pintel Eye or Cast Auto-Lock 2 5/16”)
- Heavy Duty D-Rings
- Floor, Oak Upgrade per Ln Ft.
- Floor, Steel 1/8” Diamond Plate Includes 12” O.C. Crossmembers Per Ln Ft.
- Gooseneck 12” X 14Lb. I-Beam (Includes Spare Tire, Lockable Toolbox & 2- 12K Drop Leg Jacks)
- Jack Upgrade, Adjustable Dropleg (7K in lieu of 2K) Bolt On
- Jack Upgrade, Adjustable Dropleg (10 K in lieu of 7K) Bolt On
- Ramps, 5’ Heavy Duty Spring Assist w/ Ramp Legs (7K Upgrade Only)
- Ramps, Heavy Duty Self Store (10K & 14K Only, in lieu of Stand Up) (Includes 2 - 5K Front Crank Flip up Rear Stablizer Jacks)
- 2 - 5K Front Crank Flip up Rear Stabilzer Jacks on 7K ONLY
- Rub Rail, 3/8” w/ Additional Stake Pockets per Ln. ft.(Standard on XT)
- 10” Drive over Fenders 14k Only
- 102” Wide w/ Super Duty Cleated Drive Over Fenders Per Lin. Ft. (Xtreme ONLY)
- 102” Wide w/ Super Duty Cleated Drive Over Fenders Per Lin. Ft. (CF ONLY)
- 12” Pipetop Rail Front & Sides (Per Lin. Ft.)
- 12” Pipetop Rail Front & Sides Mesh (Per Lin. Ft.)
- Upgrade to 40” Wide Ramps (Includes Mesh on Ramps)
- Tongue, per 1 ft. longer 14K ONLY
- Tongue, per 1 ft. longer Includes Adj. Coupler on 7&10K ONLY
- Dual 10K Jack Upgrade (In Lieu of Single 10K)
- Removable Fenders (No Tools Required)
- 2’ Steel Dove w/ Traction Bars
- Self Cleaning Dove CF ONLY
- Fork Holders 2 - 3” x 6” Rectangular Tube, Lockable (Either Side)
- Winch, 8,000lbs Installed with Battery Includes Solar Charger
- Winch, 12,000lbs Installed with Battery Includes Solar Charger
- Winch, 15,000lbs Installed with Battery Includes Solar Charger
- Winch Cable Wiring & Winch Plate (Winch NOT INCLUDED)
- Winch Plate
- Built in Tongue Tool Box, w. Gas Shock Assist, Lockable
- 20’ Tilt Option
Axle Upgrades
- Brake, Double Electric 7K
- Brake, Double Electric 10K
- Tri-Axle Upgrade (Upgrade Available on 14K Only-Includes 8” Main Frame &12” o.c. Crossmembers.)
- Brake Surge 7K Single
- Brake Surge 7K Double
- Brake Surge 10K Single
- Brake Surge 10K Double
- Brake Surge 14K Double
- 16K Upgrade (In Lieu of 14K) Includes 17.5 Tires & 8” Frame (GT ONLY)
- 16K Upgrade (In Lieu of 14K) Includes 17.5 Tires & 8” Frame (Xtreme ONLY)
Tires
- Spare Tire ST205/75R-15” w/ Wheel
- Spare Tire ST225/75R-15” w/ Wheel
- Spare Tire ST235/80R-16” w/ Wheel
- Spare Tire ST215/75R-17.5” w/ Wheel 16 Ply
TOUGHER THAN THE REST
At Doolittle Trailers, we understand the importance of durability and longevity when it comes to your trailer's finish. That's why we go the extra mile to ensure that our trailers are prepped and finished with top-quality materials that are built to last.
Each Doolittle trailer is prepped with a two-part Epoxy Primer, providing a strong foundation for the paint to adhere to. We then apply a two-part Polyurethane Paint finish, which has been proven to be more durable than traditional powder coat finishes. This combination of primer and paint not only enhances the appearance of your trailer but also provides superior protection against the elements, abrasion, and corrosion.
With our advanced painting process, you can trust that your Doolittle Trailer is built to handle whatever you throw at it. Whether you're hauling heavy equipment, landscaping materials, or recreational gear, our trailers are tough enough to stand the test of time, ensuring that they look great and perform reliably for years to come.
Each Doolittle trailer is prepped with a two-part Epoxy Primer, providing a strong foundation for the paint to adhere to. We then apply a two-part Polyurethane Paint finish, which has been proven to be more durable than traditional powder coat finishes. This combination of primer and paint not only enhances the appearance of your trailer but also provides superior protection against the elements, abrasion, and corrosion.
With our advanced painting process, you can trust that your Doolittle Trailer is built to handle whatever you throw at it. Whether you're hauling heavy equipment, landscaping materials, or recreational gear, our trailers are tough enough to stand the test of time, ensuring that they look great and perform reliably for years to come.
